LS Marine Solution Ltd. is recognized technique in world sea field.

Depot

Geojae Wharf

A ship depot(wharf with a length of 150m and width of 8m as well as storage facilities) capable of accommodating 2 major vessels has been constructed at shiljeonli Hacheong-myeon Geojae city Kyeongnam Province.
It is equipped with a reserve cable drum with a capacity to store up to 2,000km of cable.

  • Depot
    overview

  • Location

    1068-2 (N34 58.79, E128 39.45) Shiljeonli Hacheong-myeon, Geojae city Kyeongnam Province

  • Area

    9,279.30m2

  • Cable Storage Facility

    2,774m2

  • Transponder Storage Facility

    239m2

  • Submarine Equipment Storage Facility

    540m2

Facilities

1 Track cable engine (max speed : 135m/min, max tension : 25KN), 3 Track cable engine (max speed : 150m/min, max tension : 80KN), Cable passage, Turn wivel, Cable tower

Storage Facility Condition

The kt submarine ship depot completed construction on August 14 2000, and from early August 2001 capabilities have been improved for the best storage conditions for transponders, transfer device, and other standby equipment.

Item Temperature
Cable -20℃ ~ +50℃
Transponder 0℃ ~ +30℃
Transfer Device 0℃ ~ +30℃
  • No. of Cable Pans

    65number
    (L : 4, M : 32, S : 29)

  • Cable Tank Diameter (Large)

    interior 3m , exterior 10m , height 6m

  • Cable Pan Diameter (Medium)

    interior 3m , exterior 5.7m , height 2.9m

  • Cable Pan Diameter (Small)

    interior 3m , exterior 5.7m , height 2.3m

  • Transponder/ Conveyance Machinery for Transfer devices

    12 (Repeater : 9, BU : 4, GEU : 3, Spare Stack : 7)

  • Anchorage Capability

    Depth 8m , length 120m

The Capacity of the Wharf and Storage Facilities for Standby Equipment

The Geojae Wharf was constructed to provide optimal storage conditions for transponders, transfer devices, cable closure housing, and submarine equipments. Detailed functions are as follows.

  • a facility storing each submarine equipment at the optimal condition.
  • a facility that can maintain quick transportation of submarine equipment from the wharf to the cable vessel.
  • Comprehensive insurance for equipment and cable currently in storage.
  • Reserve equipment supplementation system in case of MA(Maintenance Authorities) requests.

Operator responsibility

To maintain optimal storage conditions to enable maintenance of each system and management so that there are no problems with equipment usage.
